Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: DC094
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
| Characteristics | Specification |
|---|---|
| Rating | 1.0A 30V |
| Actuating force | 3~20N |
| Dimension | 12.00mm*6.00mm |
| Operating life | 5,000 cycles |
| Dielectric Strength | AC500V |
| Contact Resistance | 30mΩ Max |
Apple Watch-style Power Port DC Power Jack's Product Operating Principle
--Precision Power Flow – Maintains stable current transmission in ultra-thin devices
--Controlled Insertion Force – 3-20N actuation ensures smooth plug-in without terminal strain
--Automated SMT Integration – Compatible with pick-and-place machines for mass production
JBL Clip 4-type waterproof Bluetooth Speaker DC Power Jack's Product Functions
--Micro Footprint – 45% smaller than standard DC jacks for space-critical designs
--High-Current Capability – 1A rating supports 24/7 operation in always-on IoT devices
--Low-Resistance Contacts – 30mΩ max ensures minimal power loss during charging
--Durable Design – Withstands 5,000 plug cycles and industrial vibration environments
Siemens Wireless Vibration Sensor DC Power Jack's Product Applications
Smartwatches & Fitness Bands
Example: Fitbit Charge-style side-mounted charging ports for seamless wearables
Portable Audio Devices
Example: JBL Clip 4-type waterproof Bluetooth speakers with compact power interfaces
Industrial IoT Sensors
Example: Siemens wireless vibration sensors requiring rugged, low-profile connectors
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
High effiency of production, shipped in 1 day after payment.
Q1: What industries do your PCB/PCBA services support?
A: Our PCB/PCBA solutions serve medical, automotive, energy, measurement, and consumer electronics sectors, adhering to industry-specific compliance and performance standards.
Q2: What is the process for developing custom molds?
A: Custom molds require feasibility analysis, cost negotiation, and lifespan forecasting. Submit end-product details to initiate a 5-day technical review.
Q3: Can I submit non-AI design files for quotations?
A: Yes, Gerber files, CAD models, or schematics are acceptable. AI formats ensure faster turnaround but are not mandatory for initial quotes.
Q4: What warranty and technical support accompany orders?
A: 12-month warranty against manufacturing defects. 24/7 engineering support via email/chat for integration troubleshooting.
Q5: Do you provide industry-specific certifications for medical devices?
A: Medical-grade products include ISO 13485 documentation, sterilization reports, and biocompatibility testing data upon request.
Previous: DC092 DC Power Jack
Next: DC095 DC Power Jack
