Switch Series Product Collection KKG Developing with the Green Planet
Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: DC005M
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
Model Options and Configuration Guide
The DC005M series is available in various configurations to meet different project requirements:
Pin Type: 2-pin / 3-pin
Mounting Style: Vertical / Right-angle / Panel-mount
Barrel Diameter: 2.1mm / 2.5mm
Contact Plating: Nickel or Gold (10μin)
Housing Material: High-temp thermoplastic (UL94 V-0)
Please consult our engineering team for customized terminal lengths or waterproof versions.
PreSonus Central Station-style Audio Interface DC Power Jack's Product Operating Principle
--Bilateral Contact Mechanism – Dual independent alloy springs compress from orthogonal directions to maintain plug stability under vibration
--Keyed Insertion Pathway – Directional slot ensures 100% correct plug orientation while minimizing mechanical stress during engagement
--Secure Mounting System – Panel/chassis integration completed in 90 seconds via threaded base or reflow soldering process
Reliability and Environmental Performance
To ensure dependable performance in harsh or professional environments, the DC005M DC Power Jack has been rigorously tested against international electrical and mechanical standards:
Mechanical Life: ≥5,000 insertion/removal cycles (per IEC 60603-7)
Thermal Cycle Resistance: -30°C to +100°C, no degradation after 10 cycles
Salt Spray Test: ≥48 hours (ASTM B117 standard) for corrosion resistance
Vibration Test: 10–500Hz for 2 hours in 3 axes, passed with no contact failure
Humidity Resistance: 90% RH at 40°C for 96 hours, maintains insulation resistance >100MΩ
These properties make the DC005M jack suitable for both indoor and outdoor applications where stability and contact integrity are critical.
Dahua IPC-HFW-series Weatherproof Unit DC Power Jack's Product Functions
--Industrial Durability – 3X thicker alloy contacts vs consumer-grade sockets for vibration resistance
--High-Power Delivery – 1A continuous flow for 30V systems with ultra-low resistance (≤30mΩ)
--Weather-Immune Design – IP440 protection against dust/water jets for outdoor reliability
--Thermal Resilience – Survives Arctic (-30°C) to industrial heat (100°C) extremes
Haas Automation Tooling Station DC Power Jack's Product Applications
Studio Monitor Controllers
Example: PreSonus Central Station-style audio interfaces requiring stable power in live environments
Outdoor Security Cameras
Example: Dahua IPC-HFW-series weatherproof units needing corrosion-resistant DC connectors
CNC Machine Controllers
Example: Haas Automation tooling stations with high-vibration power demands
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
High effiency of production, shipped in 1 day after payment.
Q1: May I have free samples?
A: Sure, but we need to confirm the product details before shipment. Besides, it is better to provide the AI format artwork to us.
Q2: Do you provide anti-static protection for sensitive electronics integration?
A:Yes, all connectors include ESD shielding (15kV minimum) to protect against static discharge during handling or operation.
Q3: What are the lead time and packaging options for bulk orders?
A: Standard Orders: 15-20 days, packed in anti-static tape and reel.
Custom Requests: 25-30 days, with vacuum-sealed moisture barrier bags for humidity-sensitive environments.
Q4: How do your connectors handle high-temperature soldering processes?
A: The nylon housing withstands reflow soldering up to 260°C for 10 seconds. Precise pin alignment prevents warping during PCB assembly.
Q5:How do you package the goods?
A: We will package the swtiches in reels or in anti static bag with covering air bubble films. Besides, they will be putting into a inner box and then into a outer carton.
