Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: PJ-242
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
| Characteristics | Specification |
|---|---|
| Rating | 0.5A 30V |
| Actuating force | 3~30N |
| Dimension | 12.00mm*5.00mm |
| Operating life | 5,000 cycles |
| Dielectric Strength | AC500V |
| Contact Resistance | 100mΩ Max |
Sony Alpha 7 IV Grip Headphone Jack's Product Operating Principle
1. Axial-Symmetric Signal Path - Gold-plated beryllium copper contacts maintain ≤50mΩ in 5mm width
2. Shear-Defense Mounting System - Reinforced solder anchors withstand 30N lateral force
3. Micro-Guard Reflow Shielding - Nickel barrier prevents wicking during 260°C soldering
Behringer Wing Compact Headphone Jack's Product Functions
· Critical-Width Compatibility - 5mm profile fits behind bezels in sub-6mm devices
· High-Density Audio Fidelity - ≤50mΩ resistance ensures ±0.19dB 20Hz-20kHz response
· Automation Precision - ±0.02mm placement accuracy for dense PCB layouts
· Vibration Resilience - Passes 8G random vibration per EIA-364-28D
HTC Vive XR Elite Headphone Jack's Product Applications
Digital Camera Grip Compartments
Implementation: Sony Alpha 7 IV grip headphone jack 2.5mm port
Pro Audio Mixer Matrixes
Integration: Behringer Wing compact 2.5mm audio jack cluster
VR Headset Straps
Usage: HTC Vive XR Elite 2.5mm jack headphones interface
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
We ensure high production efficiency and ship your order within 7 days after payment.
Q1:Are you a factory or trade company?
A:We are factory with more than 15 years of experience specialized in producing switches, sockets, connetors, DC Jacks, etc.
Q2:Why should we choose your company?
A:1.Porfessional manufacture with more than 15 years experience in producing various of switches.
2.Good quality, competitive price and fast delivery time.
3.OEM/ ODM Service provided to clients.
4.The best after-sale service.
Q3: How can we get the samples and best quotation?
A:We need to know more details about the products you inquired.
For example, what are the functions you need? The specification of it and which finished products will be used with it?
It is better to provide AI fromat artwork to us so we could provide best quotation to you asap.
We could provide the free samples to you.
Q4.How about the delivery time?
A: Gernally speaking it is needed 2 weeks if your quantity below 10K pcs, and it depends on the quantity.
Q5:How do you package the goods?
A: We will package the swtiches in reels or in anti static bag with covering air bubble films. Besides, they will be putting into a inner box and then into a outer carton.
