3.5 mm mini jack

FiiO M11S Portable Music Player Headphone Jack's Product Operating Principle

1. When a 3.5mm plug is inserted, internal spring contacts are displaced, establishing a secure electrical connection with the plug's terminals.

2. The contacts route audio signals (left, right, and ground) from the printed circuit board (PCB) to the connected headphones or speakers.

3. Engineered with a 3-30N operating force, it provides a firm yet smooth feel, contributing to its long-term durability over thousands of cycles.

NTI Audio XL2 Audio and Acoustic Analyzer Headphone Jack's Product Functions

1. Provides a standard interface for connecting headphones, earphones, and external speakers for audio output.

2. Enables line-in or microphone input for recording and communication in various electronic devices.

3. Ensures stable and clear audio signal transmission with minimal interference due to low contact resistance.

4. Designed for secure mounting on PCBs via a horizontal DIP layout, ideal for streamlined manufacturing processes

Testo 440 dP Air Velocity Meter Headphone Jack's Product Applications

1. Consumer Audio Devices: Integrated into the FiiO M11S Portable Music Player on the main chassis as the primary headphone output for high-fidelity sound.

2. Professional Audio Equipment: Serves as the monitor output 3.5 mm mini jack on the NTI Audio XL2 Audio and Acoustic Analyzer for real-time signal checking.

3. Industrial Control & Measurement: Utilized in the Testo 440 dP Air Velocity Meter for direct headphone output to monitor audible alarms in noisy factory environments.
