3.5 mm audio

Korg Volca Keys Analog Loop Synthesizer Headphone Jack's Product Operating Principle

1. When a 3.5mm plug is inserted, its contacts (Tip-Ring-Sleeve) align and securely connect with the internal phosphor bronze terminals of the jack.

2. The connection completes the circuit, allowing low-resistance transmission of audio signals from the source device to the connected PCB.

3. Upon withdrawal of the plug, the internal contacts disengage, instantly breaking the audio signal path with high insulation resistance.

PCE Instruments PCE-S 41 Stethoscope Headphone Jack's Product Functions

1. Provides a universal port for connecting standard headphones, external microphones, and AUX audio cables.

2. Ensures stable and clear audio signal transmission with a maximum contact resistance of 50mΩ.

3. Offers excellent durability for repeated use, with an operating force of 3-30N and a life of 5,000 cycles.

4. Guarantees robust PCB integration with its horizontal DIP design and high dielectric strength of AC 500V.

Edan F3 Fetal Monitor Headphone Jack's Product Applications

1. Consumer Electronics: Serves as the primary headphone output on the Korg Volca Keys Analog Loop Synthesizer, allowing for private audio monitoring and sound design.

2. Industrial Equipment: Integrated as the diagnostic audio output port on the PCE Instruments PCE-S 41 Stethoscope, used for listening to machine bearing noises.

3. Medical Devices: Utilized as the external 3.5 mm audio output on the Edan F3 Fetal Monitor, enabling clinicians to connect headphones to listen to fetal heart sounds.
