3.5 mm audio

Zoom H6 Handy Recorder Headphone Jack's Product Operating Principle

1. A 3.5mm plug is inserted, making physical contact with the internal spring-loaded terminals to establish a clear electrical path for audio signals.

2. Internal switching contacts are engaged or disengaged upon plug insertion, allowing for functions like automatic speaker muting or signal routing.

3. When the plug is removed, the contacts return to their default position, breaking the connection and restoring the device's original audio state.

Sony Walkman NW-A105 Headphone Jack's Product Functions

1. Provides a standard, universal port for connecting headphones, earphones, and external speakers to a device.

2. Enables line-in or microphone input, allowing for audio recording or communication through compatible accessories.

3. Ensures long-term mechanical and electrical reliability with a life of over 5,000 insertion cycles.

4. Offers a stable through-hole PCB connection, ideal for robust and compact electronic product assemblies.

Welch Allyn Connex Spot Monitor Headphone Jack's Product Applications

1. Professional Audio: In the Zoom H6 Handy Recorder, it is utilized as the dedicated headphone monitoring output, allowing sound engineers to check audio levels in real-time.

2. Consumer Electronics: On the Sony Walkman NW-A105, it functions as the primary 3.5 mm audio port for connecting high-fidelity headphones and enjoying music.

3. Medical Equipment: Used in the Welch Allyn Connex Spot Monitor, it serves as the output port for audible system alerts, alarms, and diagnostic tones through a connected earpiece.
