3.5mm SMT Horizontal Audio Phone Jack – PJ-3081

Tascam Portacapture X8 Audio Recorder Headphone Jack's Product Operating Principle

1. Secure Connection: When a 3.5mm plug is inserted, internal spring contacts firmly grip the plug, establishing a reliable and stable electrical connection for audio transmission.

2. Signal Routing: The jack routes stereo audio signals (left and right channels) and a common ground through its dedicated solder points, ensuring clear audio fidelity.

3. Durable Performance: Engineered for longevity, the mechanism is designed to withstand up to 5,000 insertion and removal cycles, guaranteeing consistent performance.

Rohde & Schwarz R&S®HMC8012 Digital Multimeter Headphone Jack's Product Functions

1. Stereo Audio Output: Delivers high-quality, two-channel stereo audio signals to headphones, speakers, and other audio peripherals.

2. Compact PCB Integration: The SMT horizontal design allows for efficient, space-saving integration onto printed circuit boards.

3. High-Fidelity Signal: With a maximum contact resistance of 50mΩ, it ensures minimal signal loss and maintains audio integrity.

4. Robust and Reliable: Built to withstand AC500V dielectric strength and an operating force of 3~30N for dependable use

iFi GO bar Portable DAC/Amp Headphone Jack's Product Applications

1. Professional Audio: Used in the headphone output stage of the Tascam Portacapture X8 Audio Recorder, allowing sound engineers to accurately monitor multichannel recordings in the field.

2. Industrial Instruments: Integrated into the Rohde & Schwarz R&S®HMC8012 Digital Multimeter as the headphone output, enabling technicians to receive audible continuity alerts without disturbing colleagues in a quiet lab environment.

3. Consumer Electronics: Serves as the primary audio output for the iFi GO bar Portable DAC/Amp, providing a high-quality connection for audiophiles to use premium headphones with this compact mini jack 3 5mm device.
