jack 3.5 mm stereo

Siemens SIMATIC HMI Comfort Panels Headphone Jack's Product Operating Principle

1. Upon insertion of a 3.5mm plug, internal spring-loaded contacts make a secure physical and electrical connection with the plug's conductors.

2. This connection establishes a clear path, transferring audio signals from the device's printed circuit board (PCB) to the attached headphones or cable.

3. The robust through-hole pins anchor the jack to the PCB, ensuring mechanical stability against the forces of repeated plugging and unplugging

Philips IntelliVue MX400 Headphone Jack's Product Functions

1. Provides a standard, universal port for connecting headphones, speakers, and other audio peripherals.

2. Engineered for a high electrical life of 5,000 cycles, ensuring long-term reliability in frequent use applications.

3. Horizontal DIP design allows for stable, through-hole mounting on PCBs, ideal for durable electronic assemblies.

4. Maintains excellent audio signal integrity with low contact resistance and high dielectric strength.

Focusrite Scarlett 2i2 Headphone Jack's Product Applications

1. Industrial Control: Utilized as the audio output port on industrial control panels, such as the Siemens SIMATIC HMI Comfort Panels, for audible system alerts and diagnostic feedback via headphones.

2. Medical Devices: Integrated into patient monitoring systems, like the Philips IntelliVue MX400, allowing medical staff to receive private audio alarms without disturbing the patient.

3. Consumer Audio: Serves as the primary headphone output jack 3.5 mm stereo on the mainboard of professional audio equipment, such as the Focusrite Scarlett 2i2 audio interface, for high-fidelity monitoring.
