3.5 mm stereo audio jack

FiiO M11 Plus Digital Audio Player Headphone Jack's Product Operating Principle

1. A standard 3.5mm audio plug is inserted, engaging with the internal spring-loaded contacts to establish a secure electro-mechanical connection.

2. The contacts transfer the left, right, and ground audio channels from the PCB to the connected headphones or external audio device.

3. Internal switching contacts can detect plug insertion, allowing a circuit to automatically redirect audio from a device's internal speakers.

Fluke 289 True-RMS Industrial Multimeter Headphone Jack's Product Functions

1. Provides a universal port for connecting headphones, speakers, and other external audio devices.

2. Engineered for high durability with an electrical life of 5,000 cycles, ensuring long-term reliability.

3. The horizontal DIP design ensures a robust, through-hole solder connection to the printed circuit board (PCB).

4. Guarantees excellent signal integrity with low contact resistance (50mΩ Max) and high dielectric strength.

GE CARESCAPE B650 Patient Monitor Headphone Jack's Product Applications

1. Consumer Electronics: On a FiiO M11 Plus Digital Audio Player, it is integrated as the primary 3.5 mm stereo audio jack for connecting a wide range of standard headphones and earphones.

2. Industrial Equipment: On a Fluke 289 True-RMS Industrial Multimeter, it serves as the audio output port for system alerts and diagnostic feedback, allowing technicians to use headsets in noisy environments.

3. Medical Devices: On a GE CARESCAPE B650 Patient Monitor, it functions as the audio jack for audible alarms or to connect a nurse's communication headset for monitoring patient vital sounds and system alerts.
