PJ-3215A: Horizontal SMT 3.5mm Audio Jack

TSI Incorporated VelociCalc 9565 Headphone Jack's Product Operating Principle

1. A 3.5mm plug is inserted, causing internal spring contacts to physically engage with the plug's tip, ring, and sleeve sections.

2. This engagement establishes distinct electrical pathways for audio channels (e.g., left, right) and a common ground connection.

3. The SMT leads provide a secure solder connection to the PCB, ensuring stable signal transfer from the jack to the device's circuitry.

TASCAM DR-40X Headphone Jack's Product Functions

1. Provides a standardized female port for connecting headphones, microphones, and other audio peripherals.

2. Enables analog audio signal transmission between a host device and an external accessory with a 3.5mm plug.

3. Its surface-mount design allows for automated assembly, saving space on compact printed circuit boards (PCBs).

4. Ensures a durable connection, rated for 5,000 insertion cycles for long-term product reliability.

Hill-Rom Welch Allyn Digital MacroView Otoscope Headphone Jack's Product Applications

1. Industrial Test Equipment: Used as a headphone output on portable environmental meters like the TSI Incorporated VelociCalc 9565 for listening to audible alarms or system alerts in noisy field environments.

2. Professional Audio: As a reliable audio jack 3 5mm headphone output on portable multi-track recorders like the TASCAM DR-40X, allowing sound engineers and musicians to precisely monitor audio recordings.

3. Medical Diagnostics: Integrated into handheld diagnostic tools such as the Hill-Rom Welch Allyn Digital MacroView Otoscope, enabling audio output for training or consultation purposes.
