3.5mm SMT Horizontal Audio Jack | Model: PJ-3278

Elektron Model:Cycles Groovebox Headphone Jack's Product Operating Principle

1. When a 3.5mm plug is inserted, it engages with the internal contacts, establishing a secure electromechanical connection for audio signals.

2. The jack’s terminals are designed to route stereo (left, right) and ground signals from the plug directly to the device's circuit board.

3. Its low contact resistance (50mΩ Max) and robust dielectric strength (AC 500V) ensure a clean, stable signal path with minimal noise or loss.

Motorola Solutions MC9300 Mobile Computer Headphone Jack's Product Functions

1. Provides a standard, universal port for connecting headphones, auxiliary cables, and other 3.5mm audio devices.

2. Facilitates clear, high-fidelity stereo audio input or output in a wide range of electronic equipment.

3. The SMT design allows for efficient, automated assembly on PCBs, reducing manufacturing time and cost.

4. Engineered with a 3-30N operating force for a satisfying and secure plug insertion and retention feel.

Suntech Vet25 Veterinary Vital Signs Monitor Headphone Jack's Product Applications

1. Professional Audio: Functions as the sync 3.5 mm input jack on the Elektron Model:Cycles Groovebox, allowing it to receive tempo information from other synthesizers or drum machines for perfect musical timing.

2. Industrial Equipment: Integrated as the headphone output on a Graphtec GL240 Data Logger, enabling an operator to directly monitor audio alerts or listen to recorded acoustic data in noisy field environments.

3. Medical Devices: Used as the primary headphone port on a Suntech Vet25 Veterinary Vital Signs Monitor, allowing veterinarians to privately listen to auscultated sounds or system notifications without disturbing the patient.
