PJ-3285 | Horizontal SMT 3.5mm Audio Headphone Jack

Astell&Kern A&norma SR25 MKII Music Player Headphone Jack's Product Operating Principle

1. When a 3.5mm plug is inserted, internal spring contacts align and make a secure connection with the plug's tip, ring, and sleeve sections.

2. This completes the electrical circuit, allowing analog audio signals from the mainboard to pass through the jack to the connected external device.

3. The SMT design provides a strong, stable solder mount to the PCB, ensuring consistent performance and resistance to physical stress.

FLIR E8-XT Thermal Imaging Camera Headphone Jack's Product Functions

1. Provides a standard analog audio output port for headphones, external speakers, and other audio peripherals.

2. Enables seamless connectivity between an electronic device's main circuit board and external audio equipment.

3. Its compact, low-profile horizontal design is perfect for space-constrained applications in modern slim electronics.

4. Engineered for high-cycle use, guaranteeing long-term reliability in products requiring frequent plug/unplug actions

Eko CORE 500™ Digital Stethoscope Headphone Jack's Product Applications

1. Consumer Electronics: Serves as the primary headphone output on the Astell&Kern A&norma SR25 MKII Music Player, providing high-fidelity audio for personal listening.

2. Industrial Instruments: Integrated into the FLIR E8-XT Thermal Imaging Camera to allow for audible alarms or voice annotations to be monitored via headphones in noisy industrial environments.

3. Medical Devices: Functions as the core 3.5 mm jack output on the Eko CORE 500™ Digital Stethoscope, enabling healthcare professionals to connect headphones for precise auscultation or to record heart and lung sounds.
