3.5 mm earphone jack

Sangean DT-250 AM/FM pocket radio Headphone Jack's Product Operating Principle

1. When an audio plug is inserted, internal spring-loaded contacts securely engage with the plug's tip, ring, and sleeve for a stable connection.

2. Audio signals travel from the device's PCB, through the jack's low-resistance contacts, and are transmitted to the connected headphones or speakers.

3. An internal switching mechanism detects the plug's presence, often used to reroute audio, such as disabling a device's internal speakers.

Fluke 190 Series II ScopeMeter Headphone Jack's Product Functions

1. Provides a standard, reliable interface for transmitting analog stereo audio signals to headphones and other audio hardware.

2. Enables secure plug-and-play connectivity for portable and stationary devices, ensuring a stable physical and electrical link.

3. Engineered for high-traffic use with a 5,000-cycle lifespan, withstanding repeated plugging and unplugging actions.

4. Designed for easy and secure through-hole (DIP) mounting onto printed circuit boards for streamlined manufacturing.

GE CARESCAPE B450 Headphone Jack's Product Applications

1. Domestic: Used as the primary headphone output port on portable audio players, such as the Sangean DT-250 AM/FM pocket radio.

2. Industrial: Integrated into handheld diagnostic equipment for audio alerts, like the headphone monitoring jack on a Fluke 190 Series II ScopeMeter.

3. Medical: Serves as the reliable 3.5 mm earphone jack on patient monitoring systems, like the GE CARESCAPE B450, for private audio alerts and communication.
