PJ-342C: Horizontal SMT 3.5mm Audio Headphone Jack

Topcon FC-6000 Field Controller Headphone Jack's Product Operating Principle

1. Upon insertion of a 3.5mm plug, internal contacts establish a secure electrical link with the plug's tip, ring, and sleeve sections.

2. The SMT design ensures audio signals are transferred efficiently from the jack directly to the PCB with minimal signal loss.

3. The 3~30N operating force provides a stable and consistent connection, ensuring reliable audio performance during use and after repeated cycles

Nihon Kohden BSM-3500 Bedside Monitor Headphone Jack's Product Functions

1. Delivers a standard 3.5mm interface for connecting stereo headphones, earphones, and auxiliary audio cables.

2. Enables clear, high-fidelity audio output for a wide range of consumer and professional electronic devices.

3. The SMT design facilitates efficient and precise placement on PCBs, streamlining the manufacturing assembly process.

4. Built to withstand 5,000 insertion/removal cycles, guaranteeing long-term performance and durability.

MOTU M2 Audio Interface Headphone Jack's Product Applications

1. Industrial Instruments: Integrated into the Topcon FC-6000 Field Controller as the primary audio output, allowing field engineers to receive critical system alerts and instructions via headphones in outdoor environments.

2. Medical Monitoring: Used in the Nihon Kohden BSM-3500 Bedside Monitor to provide an isolated headphone connection for patient audio monitoring and private alarm notifications in clinical settings.

3. Professional Audio: Functions as the essential headphone output 3.5 mm port on the MOTU M2 Audio Interface, providing artists and producers with zero-latency monitoring for recording and mixing tracks.
