Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: DC002
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
| Characteristics | Specification |
|---|---|
| Rating | 1.0A 30V |
| Actuating force | 3~20N |
| Dimension | 11.10mm*5.00mm |
| Operating life | 5,000 cycles |
| Dielectric Strength | AC500V |
| Contact Resistance | 30mΩ Max |
Samsung Galaxy Tab-style Charging Port DC Power Jack's Product Operating Principle
--Dual-Spring Stability – Balances electrical flow in compact devices via elastic terminal design
--Precision Insertion Guide – Ensures correct plug alignment to prevent misinsertion damage
--Fast PCB Integration – DIP pins enable quick soldering onto standard boards
Omron Blood Glucose Monitor DC Power Jack's Product Functions
--High Current Capacity – 1.0A rating (double DC012A) for 5V/12V systems with ultra-low resistance (≤30mΩ)
--Long-Term Durability – 5,000+ plug cycles tested under extreme temperature (-30°C to 70°C)
--Safety-Certified Build – AC500V dielectric strength + IP40 dust protection for industrial environments
--Cost-Efficient Design – Optimized material use reduces production costs by 20% vs. standard sockets
DJI Mini 2 controller DC Power Jack's Product Applications
Smartphones & Tablets
Example: Samsung Galaxy Tab-style charging ports with 3.5×1.3mm compatibility
Portable Medical Devices
Example: Omron blood glucose monitors requiring stable 12V power input
Mini Drones
Example: DJI Mini 2 controllers with space-constrained power interfaces
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
High effiency of production, shipped in 1 day after payment.
Q1: Are you a factory or trading company?
A: We are the leading manufacturer of electronics. Why not conatct us now to discover original factory prices!
Q2: Why should we choose your company?
A:1.Porfessional manufacture with more than 15 years experience in producing various of switches.
2.Good quality, competitive price and fast delivery time.
3.OEM/ ODM Service provided to clients.
4.The best after-sale service.
Q3: When can I get the quotation?
A: We will send you quotation within 24 hours after providing product details.
Q4:Can you provide samples?
A: Yes! Free samples! Only shipping fee needs to be paid.
Q5. What is the payment term?
A: For small quantity order, pls remit payment by PayPal. For bulk order, pls remit payment by T/T.
