2-Port Stacked Shielded Network Interface Socket with LEDs

Dell PowerEdge T40 RJ45 Socket's Product Introduction

KKG Electronics presents the RJ45-880A 2X1, a high-performance rj45 connector designed to optimize port density in networking equipment. This "stacked" module integrates two shielded 8P8C ports vertically, effectively doubling connectivity without increasing the horizontal footprint on the PCB. The robust metal shell acts as a Faraday cage, grounding the rj45 socket to protect data integrity from electromagnetic interference. Ideally suited for high-speed applications, it features integrated LEDs to provide immediate visual diagnostics of link activity and speed. The unit is engineered to securely latch with any standard plug, ensuring a stable physical connection. As a reliable rj45 jack, it utilizes gold-plated contacts and through-hole shielding tabs, making it the preferred rj45 connector socket for enterprise switches, servers, and industrial gateways requiring reliable dual-port connectivity.

Cisco Catalyst 9200 RJ45 Socket's Product Operating Principle

Vertical Port Integration: The thermoplastic housing molds two distinct jack cavities one above the other allowing two separate Ethernet cables to connect to the PCB sharing a common structural alignment.
EMI Shielding: The external metal chassis surrounds the entire connector block and connects to the PCB ground plane via tabs to drain electromagnetic noise away from the signals.
Status Indication: Internal LED circuits embedded in the housing face illuminate when triggered by the device logic to show network activity or link speed for both the top and bottom ports.v

Rockwell Automation Allen-Bradley RJ45 Socket's Product Functions

Port Density Maximization: Doubles the available network connections on the rear panel of a device without requiring a longer circuit board making it ideal for compact switches and servers.
Signal Interference Protection: Protects sensitive differential data pairs from electromagnetic interference (EMI) and radio frequency interference (RFI) using the conductive metal housing.
Network Diagnostics: Provides users and technicians with immediate at-a-glance feedback on the connectivity status of each port via the built-in LEDs without needing software access.
Secure Physical Anchor: Utilizes multiple through-hole shield tabs to solder firmly into the circuit board providing exceptional shear strength to withstand the weight of two attached network cables.

Network Switches: Integrated into the port array of the Cisco Catalyst 9200 Series to provide high-density shielded connectivity for enterprise networks.

Network Attached Storage: Used on the rear I/O panel of the Synology DiskStation DS923+ to allow for link aggregation and failover support.

Industrial Controllers: Located on the communication module of the Rockwell Automation Allen-Bradley PLC to handle dual-network redundancy in factory floors.

Media Servers: Integrated into the motherboard of the Dell PowerEdge T40 Tower Server to ensure reliable high-bandwidth data uplink.
