6*6 Illumination Tactile Switch

The button switch with light is a control switch with manual operation (finger or palm), indicator light and energy storage reset.

Assembly process of light touch switch:

1 Wire tail treatment: cut the wire tail flat, do not hit the carbon paste on the back of the terminal - a layer of single-sided adhesive pet for reinforcement. When it is necessary to hit the terminal,

lead the front of the terminal to the terminal riveting pressure. Note that the double tail line should be cut at the 1.5 cm rounded outlet at the bottom of the tail line.

2 Punching: on the assembled circuit, the four corners are aligned, the open hole is extended by1 mm, connected all around, and bound to the assembled circuit. Knock it down with something.

When knocking on the door, be careful if the line is hit.

3 Stamping forming: the standard requires accuracy. According to the supplied standard, the thickness, standard and shape of printing materials, the standard of touch switch is subject to

variable processing to obtain accurate structural standard. The quality of stamping die is the key to directly affect the forming quality of light touch switch shell. High quality convex pressing adopts

hot pressing. Its advantage is that the kneading convex shape is not deformed, with a sense of hierarchy and three-dimensional feeling.

4 Inspection: check whether there is any appearance deviation and poor silk screen printing. Then, according to the circuit principle, check one by one and touch the band lights

Lamp switches'Features

•Multiple cap options: Lettering, Graphic,Custom legends Transparent, Silver plating, Balck painting, UV coating Round, Square, Rectangle, Customized caps

• Sharp tactile response

• Mount options: THT, SMT

• Illumination options: Single colors, Bi-colors

•RoHS compliant and compatible

Materials

LED Specifications

Lighting function: Equipped with built-in LED indicator lights, it can provide two lighting modes: low intensity and high intensity, and has multiple color options (such as blue, green, yellow, red, etc.) to meet the needs of different application scenarios.

Operation tactile sensation: The design of the touch switch allows users to easily perceive the operation status of the switch through tactile sensation, accompanied by obvious click sound feedback, enhancing the user experience.

Electrical performance: It has a high electrical lifespan, typically exceeding 500000 electrical operation cycles, ensuring the stability and reliability of the switch.

Materials and Design: Made of stainless steel, silver coated high-temperature thermoplastic material (UL94-V0), and silver plated brass, it has good corrosion resistance and high temperature resistance. At the same time, two different styles of transparent hats, circular and square, are provided to meet different design needs.

2、 Application Fields

The 6 * 6 Illumination tactile switch is widely used in various designs that require lighting interfaces due to its unique lighting function and stable electrical performance, including but not limited to:

Industrial equipment: In complex industrial environments, lighting touch switches can help operators identify and operate equipment more clearly.

Building automation/HVAC equipment: In building automation and HVAC systems, this switch can be used to control the operating status of various equipment.

Instrumentation: In measuring and testing equipment, illuminated tactile switches can be used to select functions or set parameters.

Communication equipment: In the field of communication, this switch can be used to control the on/off status of devices such as telephones and routers.

Control equipment: In electrical control systems, lighting tactile switches can be used to control functions such as starting, stopping, and turning of motors.

3、 Purchase suggestions

When choosing a 6 * 6 Illumination Tactile Switch, the following factors need to be considered:

Lighting requirements: Choose the appropriate LED intensity and color according to the application environment.

Operating power: Select the appropriate operating power range based on the usage scenario and the needs of the operator.

Electrical performance: Ensure that the electrical life and rated current of the selected switch meet the application requirements.

Packaging design: Consider factors such as the size, shape, and color of the switch packaging to ensure coordination with the overall design.

4、 Precautions

Installation: During the installation process, ensure that the pins of the switch are correctly aligned with the solder pads on the circuit board, and avoid excessive force that may cause the pins to bend or be damaged.

Usage: During use, frequent excessive pressing or excessive external force should be avoided to avoid affecting the electrical performance and lifespan of the switch.

Maintenance: Regularly clean and maintain the switch to ensure its normal operation and extend its service life.
