Upright Mount Manual Insertion SD Card Interface

Keysight DAQ970A TF Card Connector's Product Introduction

KKG Electronics presents the TF-4052, a specialized interface designed for applications requiring full-size SD cards in a vertical orientation. Unlike flat-mounting options, this "Upright" connector allows the media to stand perpendicular to the circuit board, significantly saving horizontal PCB real estate. While many modern devices shrink to a micro sd connector, professional equipment often retains the Standard SD format for durability and handling ease. The TF-4052 features a robust thermoplastic housing that guides the card securely into the contact zone. It serves as a reliable micro sd socket counterpart for larger media, utilizing precision contacts to ensure data integrity. Designers often compare its vertical utility to a micro sim card holder in communication boards, but this unit is specifically engineered for high-capacity Secure Digital memory. Its simple manual insertion mechanism eliminates complex springs, enhancing long-term reliability. As a durable micro sd card socket alternative for full-size cards, it is perfect for kiosks and data loggers.

Creality Ender 3 TF Card Connector's Product Operating Principle

Vertical Insertion: The user manually aligns the Standard SD card with the top slot and pushes it downward until it bottoms out against the housing stops ensuring alignment.
Friction Retention: Internal high-tension spring contacts apply lateral pressure to the card's gold pads holding it securely in place without the need for a complex latching mechanism.
Presence Detection: As the card reaches its full depth a mechanical leaf switch is physically deflected closing the circuit to signal the host processor that media is ready for access.

Zoom LiveTrak L-8 TF Card Connector's Product Functions

Space Optimization: Minimizes the horizontal footprint on the motherboard by utilizing vertical Z-height allowing for tighter component packing in compact enclosures.
Data Interface: Provides a reliable 9-pin connection for the SD bus allowing the device to perform high-speed read and write operations to the external memory.
Structural Stability: Features reinforced through-hole solder pegs that anchor the tall housing firmly to the PCB preventing the socket from snapping off during card insertion.
User Accessibility: Positions the card slot at the top or edge of a device casing making it easy for users to swap cards in rack-mounted or wall-mounted equipment.

3D Printers: Integrated into the control board of the Creality Ender 3 to allow users to load G-code print files vertically from a standard SD card.
Digital Signage: Used on the media player unit of BrightSign players to load video content in tight wall-mounted digital display enclosures.
Industrial Data Loggers: Located on the top panel of the Keysight DAQ970A Data Acquisition System for easy retrieval of measurement logs.
Audio Equipment: Integrated into the mixer board of the Zoom LiveTrak L-8 to provide multi-track recording capabilities on robust media.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.

Q1:Are you a factory or trade company?

A:We are factory with more than 15 years of experience specialized in producing switches, sockets, connetors, DC Jacks, etc.

Q2: What is the turnaround time for rapid prototyping of modified designs?

A: Prototypes are delivered in 7-10 working days post-design approval. Submit CAD files and specifications to activate priority engineering review.

Q3: How do you ensure long-term product availability for legacy systems?

A: We guarantee 15-year lifecycle support with EOL (End-of-Life) notifications 24 months in advance and bridge manufacturing options.

Q4: Can you accept small order? Like 1000 pcs or 2000 pcs?
A: Sure, but we suggest you buy more, because it really can save your time and freight charge in the near future.

Q5:What kind of files are required for quotation?
A: For PCB quotation, please provide the Gerber data / files and indication of related technical requirements as well as any special.
