Surface Mount CF Card Interface Connector

Cisco 2800 Series TF Card Connector's Product Operating Principle

Pin Engagement: The connector features two rows of 25 male pins spaced at 0.635mm which penetrate the female receptor holes of the Compact Flash card to establish electrical contact.
Card Guidance: Extended plastic arms on the left and right sides physically guide the card chassis during insertion to ensure the delicate pins align perfectly with the card interface.
Parallel Transmission: The 50 pins operate on a parallel ATA (PATA) interface standard allowing for simultaneous multi-bit data transfer between the host controller and the memory controller.

Tascam DA-6400 TF Card Connector's Product Introduction

KKG Electronics presents the TF-3231, a professional-grade 50-pin header designed to interface with Compact Flash storage media. Unlike the miniaturized form factor of a nano sim card connector used in cellular devices, this CF header provides a substantial, rugged interface for industrial controls and professional audio equipment. The connector features long guide rails to ensure precise card alignment before the pins engage, preventing damage to the contact array. While modern mobile devices rely on a micro sim socket for identity, industrial PCs often utilize the TF-3231 for their primary boot drive or data logging due to the robustness of CF cards. The unit is constructed with high-temperature LCP plastic to withstand reflow soldering. Engineers designing complex embedded systems may place this alongside a micro sim connector to handle heavy data storage while the SIM handles telemetry. Its gold-plated pins ensure low contact resistance, offering a durability level far exceeding that of a standard consumer micro sim card connector.

Professional Audio: Integrated into the recording slot of the Tascam DA-6400 Multi-Track Recorder to provide stable high-bandwidth storage for live audio capture.
Industrial Controllers: Used on the CPU board of the Fanuc Series 0i CNC Machine controller to load part programs and system parameters.
Legacy Networking: Located on the expansion module of older Cisco 2800 Series Routers to house the operating system IOS image on a removable flash card.
Vintage Photography: Integrated into the memory slot of the Canon EOS 5D Mark II DSLR camera to buffer and store high-resolution RAW images.
