Product Details
Place of Origin: Dongguan China
Brand Name: KKG
Certification: CE / SGS / ISO9001
Model Number: USB-UF003F
Payment & Shipping Terms
Minimum Order Quantity: 500pcs
Price: Negotiate
Packaging Details: Plastic bag+ inner box bubble+ inner box in Carton
Delivery Time: 3-5 Days
Payment Terms: T/T, L/C, Western Union
More Details please find the below websties:
Product Overview
This industrial-grade USB connector is engineered for high-reliability data and power transmission in automotive, industrial, and smart control systems. Featuring a 1.5mm elevated socket, it provides layout flexibility and under-board component clearance, ideal for compact, multi-layer PCBs. Designed for harsh environments and high-throughput manufacturing, it’s suited for EV modules, laser control boards, and building automation devices.
| Characteristics | Specification |
|---|---|
| Current Rating | 1.5A/contact terminal |
| Voltage Rating | 30V DC |
| Contact Resistance | 30MΩ |
| Dimension | 10.00mm*13.10mm |
| Dielectric Withstabding Voltage | 100V DC |
| Insulation Resistance | 100MΩ min |
BYD Modules for Canbus Data Port USB Connector's Product Operating Principle
The 1.5mm raised socket creates under-PCB clearance to bypass nearby components, saving 30% rework vs standard DIP. Wave-soldered through-hole pins maintain<0.3ω impedance="" during="" 20m="">
Product Advantages
1.5mm elevated socket reduces layout interference for denser PCBs
Wave-soldered through-hole pins ensure low impedance (<0.3Ω) under thermal stress
MIL-STD-883H certified for durability under shock, vibration, and temperature extremes
Compatible with high-speed USB 2.0 + BC1.2 charging (up to 2.0A)
Designed for salt-spray, automotive-grade, and multi-layer PCB environments
High-speed production: 40,000 units/hour with wave soldering
Epilog-style Control Board USB Connector's Product Functions
--Elevated Socket Design: 1.5mm lift avoids capacitor/resistor collisions on Back of PCB.
--Industrial-Grade Durability: MIL-STD-883H certified (vibration/shock/thermal cycling).
--USB 2.0 Hi-Speed+: 480Mbps + BC1.2 charging protocol (2.0A max).
--Extreme Environment: -40°C~125°C operation with 1,000hr salt spray resistance.
--High-Volume Ready: Wave soldering achieves 40,000 units/hour throughput.
Honeywell T6-style Thermostats USB Connector's Product Applications
EV Battery Management Systems
Example: Integrated into BYD Blade-style modules for elevated CAN bus data ports.
Industrial Laser Cutters
Example: Powers Epilog-style control boards with clearance for heatsink installations.
Smart Building Controllers
Example: Deployed in Honeywell T6-style thermostats for multi-layer PCB architectures.
KKG Electronics, each part of the use of temperature-resistant materials, high-temperature testing equipment 260 ℃ for 5 minutes, the appearance of the product does not change!
High effiency of production, shipped in 1 day after payment.
Q1. What's your lead time?
A: Gernally speaking it is needed 2 weeks if your quantity below 10K pcs, and it depends on the quantity.
Q2. Are you a factory or trading company?
A: We are the leading manufacturer of electronics. Why not conatct us now to discover original factory prices!
Q3. How can you ensure the quality?
A: All our products are 100% tested before delivery. Durable quality is guaranteed.
Q4. Can you provide samples?
A: Yes, we offer free samples and you only need to bear express charge.
Q5. What is the shipping cost?
A: Depending upon the quantity and the destination, we will check for you if you provide the information to us.
