8P8C Network Interface PCB Socket

Samsung SmartThings Hub RJ45 Socket's Product Introduction

KKG Electronics presents the RJ45-524T, a robust network interface component designed to meet the demands of modern data communications. This socket is engineered to securely accept a standard rj45 head, providing a tactile click upon insertion to confirm a solid mechanical lock. It serves as the critical entry point for any rj45 connector board layout, allowing devices to link seamlessly to local area networks. While physically larger than a telephone-grade rj45 connector 4 pin (often confused with RJ11), this 8-pin rj45 socket offers the full connectivity required for Gigabit Ethernet, supporting all four twisted pairs in a standard Cat5e or Cat6 cable. The unit features a reinforced housing structure that withstands the leverage forces of stiff network cables, protecting the solder joints on the PCB. With reliable insulation and precise contact geometry, the RJ45-524T is an essential component for routers, switches, and industrial control systems requiring stable connectivity.

Dell Latitude 5520 RJ45 Socket's Product Operating Principle

Mechanical Mating: The flexible tab on the cable plug engages with the internal ramp and notch of the socket housing creating a secure snap-fit that resists accidental removal.
Wiping Contact Action: As the plug is inserted the internal spring contacts slide against the gold-plated blades of the plug removing surface oxidation to ensure a clean electrical path.
Signal Routing: The internal lead frame directs the differential signals from the twisted-pair cable pins down to the PCB footprint maintaining impedance matching to minimize data loss.

Ubiquiti UniFi 6 Lite RJ45 Socket's Product Functions

Network Interfacing: Acts as the physical bridge between the external Ethernet cabling infrastructure and the internal network interface controller chip of the device.
Cable Retention: Provides a robust mechanical anchor that holds the network cable firmly in place preventing connection dropouts due to vibration or movement.
Standard Compliance: Adheres to universal TIA/EIA wiring standards to ensure complete interoperability with standard patch cords and networking gear globally.
Signal Isolation: Maintains physical separation between the conductive data lines to prevent short circuits and crosstalk between transmit and receive pairs.

Wireless Access Points: Integrated into the PoE port of the Ubiquiti UniFi 6 Lite to provide both data connection and power delivery.

Laptop Computers: Used on the side I/O board of the Dell Latitude 5520 to allow for hardwired enterprise network connections.

Industrial PLCs: Located on the communication module of the Siemens SIMATIC S7-1200 to facilitate industrial Ethernet control protocols.

Smart Home Hubs: Integrated into the rear panel of the Samsung SmartThings Hub to connect the device to the home internet router.

KKG Electronics uses temperature-resistant materials and high-temperature testing equipment.

The product's appearance does not change when tested at 260°C for 5 minutes!

We ensure high production efficiency and ship your order within 7 days after payment.
